Тип вентилятора [AC/DC]AC переменного тока | КонструкцияОсевой | Уровень шума [dB/A]61 |
БрендEbmpapst | Вес [кг]2.85 | Производительность [м3/ч]975 |
Частота [Гц]50 | Питание [В]230 | Частота вращения [об/мин]1320 |
Тех описание Hyblade Ebmpapst S4E300-AS72-31 - RU | |
Каталог Hyblade 2012 350-450 мм - EN | |
Каталог Hyblade 2010 500-910 мм - EN |
S4E300-AS72-31 решение задач в области вентиляционной техники
Для множества применений в области вентиляции ЭБМ-ПАПСТ предлагает наиболее подходящие решения. Для решения Вашей конкретной задачи всегда найдется оптимальное решение за счет множества комбинаций различных характеристик двигателя, рабочего колеса и устройств управления.
Критерии выбора
При выборе вентилятора для конкретного применения важную роль играют следующие параметры:
- Производительность при заданном противодавлении (сопротивлении)
- Напряжение питания – постоянное и переменное (1- / 3-фазное)
- Уровень шума
- Коэффициент полезного действия
- Имеющееся пространство для монтажа и место применения
- Количество штук
- Условия окружающей среды (влажность, температура,климат)
- Диаметр рабочего колеса
Описание S4E300-AS72-31:
- Класс защиты: IP 44
- Класс изоляции: "B"
- Защита двигателя: температурный предохранитель выведен
Рабочие параметры вентилятора S4E300-AS72-31
Тип S4E300-AS72-31 | |
Мотор M4E068-CF | |
Фаза | 1~ |
Номинальное напряжение VAC | 230 |
Частота Hz | 50 |
Метод опред. данных | мн |
Соответствует нормативам | CE |
Скорость вращения min-1 | 1320 |
Входная мощность W | 72 |
Потребляемый ток A | 0,32 |
Конденсатор ?F | 2 |
Напряжение конденсатора VDB | 400 |
Макс. противодавление Pa | 60 |
Мин. темп. окр. среды °C | -25 |
Макс. темп. окр. среды °C | 50 |
Пусковой ток A | 0,6 |
Техническое описание S4E300-AS72-31
Вес | 2,80 kg |
Размер двигателя | 300 mm |
Покрытие ротора | С лакокрасочным покрытием черного цвета |
Материал лопастей | Напрессованная, круглая листовая заготовка, с полимерным покрытием PP |
Количество лопастей | 5 |
Направление потока | A |
Направление вращения | Справа, вид на ротор |
Степень защиты | IP 44; в зависимости от монтажного положения |
Класс изоляции | B |
Класс защиты от влажности | F1-2 |
Максимально допустимая темп. окружающей среды электродвигателя | + 80 °C |
Минимально допустимая темп. окружающей среды электродвигателя | - 40 °C |
Положение при монтаже | Любое |
Отверстия для отвода конденсата | - |
Режим работы | S1 |
Устройство подшипников электродвигателя | Шарикоподшипник |
Контактный ток по IEC 60990 (измерительная схема рис. 4, TN-система) | 0,75 mA |
Защита двигателя | Реле контроля температуры (TW) с внутренней разводкой |
Вывод кабеля подключения | Разл. |
Класс защиты | I (если защитный провод подключен стороной заказчика) |
График рабочей точки
Схема электрического подключения
Расшифровка наименовани
1) Тип
- A - осевой вентилятор
- S - осевой вентилятор с защитной решеткой
- W - осевой вентилятор со стеновым колесом
2) Количество полюсов (для AC) / Количество контуров (ЕС)
3) Тип двигателя
- D - Трехфазный двигатель
- Е - Однофазный двигатель с пусковым конденсатором
- G - ЕС-двигатель
- S - Двигатель с расщепленными полюсами
- Q - Квадратный двигатель с расщепленными полюсами
4) Диаметр рабочего колеса в мм / Размер двигателя для двигателя
5) Код механического исполнения
6) Код электрического исполнения
7) Код вариантов механического исполнения
Тип вентилятора [AC/DC] | AC переменного тока |
---|---|
Конструкция | Осевой |
Уровень шума [dB/A] | 61 |
Бренд | Ebmpapst |
Вес [кг] | 2.85 |
Производительность [м3/ч] | 975 |
Частота [Гц] | 50 |
Питание [В] | 230 |
Частота вращения [об/мин] | 1320 |
Мощность [кВт] | 0.072 |
Давление [Pa] | 60 |
Типоразмер [мм] | 300 |
Сила тока [A] | 0.32 |
Исполнение | Решетка |
